0.9-Mtr Ku-Band Backpack Antenna System

Calling themselves “The Oldest, New Antenna Company On the Planet,” Alpha Satcom Inc. has just received a contract award from Waldo Systems Co., Ltd., South Korea, to supply that firm with a 0.9 meter, Ku-Band, backpack antenna system. Waldo Systems provides a wide range of satellite systems and related products to all sectors of the Korean market.  Having worked with …

7.3-Mtr and 9.0-Mtr Hub Typical Ka-Band Integration

All Alpha Satcom antennas are designed for Ka-Band operation and include exceptionally large hubs which provide not only exceptional stiffness to the reflector structure but also a generous volume for the integration of Ka-band Rf sub-system equipment.

4.2-Mtr Ka-Band Turning Head Antenna

A 4.2-mtr Carbon Fiber Gregorian turning head antenna that supports X-band, X-band Lo-PIM, Ku-band and Ka-band operations with a switchable feed.  The specially designed large hub is designed to house a full complement of RF components.  The azimuth coverage is via a +/_ 170 ° slew gear and the elevation is 5° to 90° via a self-locking, anti-back lash, mechanical …

6.2-Mtr C-Band High Wind Antennas

Reaching ever higher, Alpha is finalizing the installation of two, 6.2-mtr, C-band, High Wind Antennas poised over 29 stories above the sidewalk in the Chai Wan area of Hong Kong. If you think assembling and testing not one, but two, such systems so high above terra firma is challenging then you are correct. The antennas will be looking heavenward but …

7.3-mtr Ka-Band

The first of two (2) 7.3-meter Ka-band antennas being installed at the TSN Teleport in Malaysia.  Ka-band business is growing in the region in-spite of high temperatures and extremely heavy down pours during the monsoon season.  Alpha Satcom will design and maintain insulated hubs with air conditioning systems based on the internally generated sensitive heat loads and ambient design conditions.

9.0-Mtr 6-Port DBS Band

The large hub permits the installation of the amplifiers close to the feed in order to reduce the loss associated with the high frequency waveguide.

9.0-Mtr Ka-Band Monopulse

Alpha Satcom 9.0-mtr Ka-band Antenna complete with mono-pulse tracking at a NATO site in Europe. The antenna was designed with a mono-pulse feed and control system permitting it to be used for TTAC operation.  The reflector also includes an Anti-Icing system dictated by the weather conditions at the site.

Alpha Satcom’s 9.0-mtr Ka-Band

Alpha Satcom 9.0-mtr Ka-band Antenna with a Smart Step Track Antenna Control System and 1:1 Air Conditioning System installed in Adelaide, Australia.  9.0-mtr Ka-band and smaller antennas, not required for TTAC or IOT Ranging Services, can be supplied and operate with a good quality Smart Step Track Antenna Controller with Predictive Track capability. Alpha Satcom’s rapid push for production and …
